Conveyer belt mesh

Material:Stainless steel wire,medium or low carbon steel wire ,aluminum wire, nickel chromium wire etc.
Weaving:Common weaving,strengthened weaving,sectional common weaving etc.
Diameter:0.8-2mm
Width: 0.3-3m
Length:0.5-100m

1. Materials:

Stainless steel wire, stainless iron wire stainless iron wire middle and low carbon steel wire galvanized iron wire nickel chromium wire iron chromium aluminum wire polyester wire etc.

2. Weaving and characteristics:

The shape of organization structure including ordinary weaving reinforce weaving, parts ordinary weaving etc.

3. Application:

Wire mesh conveyer belt is widely used in petroleum, metallurgy, food machinery, medicine, glass, circuit
panel, etc.

4. Specifications:

Mesh Diameter (mm)	Other Mesh Diameter (mm)	Other Mesh NO./m	Mesh NO./m
4	6	33radix	40circle
3.5	3.5	33radix	40circle
2.8	2.8	52radix	60circle
2	2	57radix	71circle
2.8	2.8	72radix	80circle
2.8	3	92radix	100circle
2.8	2.8	105radix	118circle
2.8	2.8	60radix	138circle
1.6	1.6	72radix	80circle
1.6	1.6	105radix	118circle
1.6	1.6	125radix	138circle
1.6	1.6	158radix	158circle
1.2	1.2	92radix	100circle
1.2	1.2	105radix	118circle
1.2	1.2	92radix	138circle
1.2	1.2	158radix	158circle
0.9	0.9	158radix	158circle
