Materials:
iron wire,plastic wire,Aluminum alloy wire,fiberglass wire
Assortments:
•Enameled Wire Mesh
•gal. Iron Wire Mesh
•Painted Iron Wire Mesh
•PVC-Coated Iron Wire Mesh
•Epoxy-coated Wire Mesh
•Aluminum Alloy Wire Mesh
•Fiberglass Wire Mesh
•Plastic Wire Mesh
Mesh: 20×20,18×18, 18×16, 18×14,16×16 ,14×14
Thickness: 0.23-0.26mm
Width: 2', 2.5', 3 ', 3.5', 3.75', 4', 4.5', 5', 6', 7', 8'
Length: 50',100'
|
Specification List of Window Screen Netting |
|
Variety |
Specification |
Technical Notes |
|
Mesh/Inch |
Wire Gauge |
Roll Size |
|
Gal.Iron Enamelled Window Screening |
10 x 10 |
BWG31
BWG32
BWG33
BWG34 |
|
3"x100" |
|
4"x100" |
|
1x25M |
|
1.2x30M |
|
1.5x25M | |
Process: Electric galvanized after weaving
Color: White or Light-blue |
|
14 x 14 |
|
16 x 16 |
|
18 x 18 |
|
18 x 14 |
|
22 x 22 |
|
24 x 24 |
|
Spray Window Screening |
10 x 10 |
BWG31
BWG32
BWG33
BWG34 |
3"x100"
4"x100"
1x25M
1.2x25M
1.5x25M |
White, Black, Blue, Green, Red |
|
14 x 14 |
|
16 x 16 |
|
18 x 18 |
|
18 x 14 |
|
22 x 22 |
|
24 x 24 |
|
Aluminum Wire Window Screening |
10 x 10 |
BWG31
BWG32
BWG33
BWG34 |
3"x100"
4"x100"
1x25M
1.2x25M
1.5x25M |
Material: Al-mg.alloy or Enamelled Aluminium Window Screening |
|
14 x 14 |
|
16 x 16 |
|
18 x 18 |
|
18 x 14 |
|
22 x 22 |
|
24 x 24 |
|
Fiberglass Window Screening |
10 x 10 |
BWG31
BWG32
BWG33
BWG34 |
3"x100"
4"x100"
1x25M
1.2x25M
1.5x25M |
Green Or Dark Green |
|
14 x 14 |
|
16 x 16 |
|
18 x 18 |
|
18 x 14 |
|
22 x 22 |
|
24 x 24 |
|
Plastic Wire Window Screening |
12x 12 |
BWG31
BWG32 |
3"x100"
4"x100"
1x25M
1.2x25M |
Twisted weaving:12 14 16mesh;
Plain weaving:18 22 24mesh;
Colors available:white,blue,green,etc. |
|
14 x 14 |
|
16 x 16 |
|
18 x 18 |
|
22 x 22 |
|
24 x 24 |
|
Stainless Steel Wire Screening |
14 x 14 SWG38
16 x 16 SWG37
18 x 18 SWG36
18 x 14 SWG35
20 x 20 SWG34 |
3"x100"
4"x100"
1x25M
1.2x25M |
Materials: Stainless steel 304 316 316L |
|
PVC Coated Wire Screening |
12x 12 |
BWG31
BWG32 |
3"x100"
4"x100"
1x25M
1.2x25M |
Suitable For Petroleum, Pipeline, Package. All Kinds of color |
|
14 x 14 |
|
16 x 16 |
|
18 x 18 |
|
