Filter Press Cloth(bag)

Filter Press Cloth(bag)

1: The air filter cartridge adopts imported fiber as filter material ,compounded with advanced folded technology,which makes the air filter with large filter area, small hole diameter, high efficiency,etc.

2: The material for cover and frame is galvanized plate, with perfect anti-corrosion and anti-rusty performance.

1 Filter Press Cloth(bag) Usage:Used for plate,and frame filter press,chamber press and other presses
2 Material: PET,PA.PP,etc
3 usage:
Filter press requirements are met using wide range of cloths ; Cloths for traditional filters Twin cloths with a connection neck for automatic filter presses (sizes up to 2150mm) Cloths for membrane plates Cloths for sealed edges and reinforcements Under-cloths for drainage other details matching machine needs (upon request).
4 Filter Press Cloth(bag)Application:
Widely used in liquid/solid,separation gas filtration and dust collection,several industries:pertrochemical,ceram.
5.Properties filter cloth:
Anti Acid,
Anti Akalic,
Oxygenation resistant
High tensile strength,
Moisture resistant,
Suite high temperature working conditions

In order to ensure the filter cloth tightness with filter plate, latex (glue) will be brushed. For filter cloth construction, we use rubber neck, velcro, banding, neck (butterfly type), metal,plastic hole, etc.
Note: We can weave different Denier fibre/yarn into different weaving (plain, twill, satin ) to form different filter efficiency and requirement from different customers, also we can make as offerd sample of filter cloth!

Model no	weaving	material		Density /10cm		Weight(g/m²)	Splitting strength(N/5*20cm)		Air permeability(L/m².s)	Thickness(mm)
Model no	weaving	warp	weft	warp	weft	Weight(g/m²)	warp	weft	Air permeability(L/m².s)	Thickness(mm)
621A	Plain	Polyester filament	Polyester filament	193	130	340	2950	1950	55	0.65
621B	Plain	Polyester filament	Polyester filament	260	145	440	3800	2100	60	0.6
3927	Plain	Polyester staple fiber	Polyester staple fiber	157	105	538	3950	2800	20	1
734	Twill	Polyester staple fiber	Polyester staple fiber	232	166	245	1800	1250	450	0.6
747	Plain	Polyester staple fiber	Polyester staple fiber	226	158	260	2000	1350	125	0.5
758	Plain	Polyester staple fiber	Polyester staple fiber	195	134	330	2450	1750	98	0.75
208	twill	Polyester staple fiber	Polyester staple fiber	260	275	400	2400	1900	225	1.5
